X.I.A.T: Hover Platform Current Status: PROTOTYPE This project is currently only a design, and will remain so until my disposable income returns. |
Overview:
X.I.A.T. (X.I.A.T. is a thesis) is a flying
platform.
The design is very simple. Four vertically oriented
electric ducted fans support a square platform by its corners. Two
spin counter clockwise and two spin clockwise.
ccw | cw | cw | ccw |
Rotation:
If all the fans were spinning in the same direction, the retarding force of
the air apon the blades would cause the craft to spin in the opposite
direction. By using half in each direction you not only cancel that force
out, but you provide the ability to make radial turns. By increasing
the power to one set and decreasing power to the other, you can
remain level and allow frictional forces to turn the craft.
ccw | cw | cw | ccw |
Translation:
Translation would be attained by lifting one side of the craft so that the
verticle jets would have a horizontal component to their force. The
thrust would have to be increased as well during this manuver to remain
level. Once velocity is attained, the craft can level to a very near
horizontal position where the acceleration in the direction of
velocity is near that of the retarding forces. To stop it needs simply
tilt against the direction of motion.
ccw | cw | cw | ccw |
Sensors:
A piezo gyro
on the plane of the craft can regulate the rotational rotation of the
craft. This sensor provides a servomotor wave pulse proportional to the
angular acceleration. This can be utilized as a sensor or as a direct
control to the motors, until I purchace one and play around with it I dont
know how it will be used.
Three accelerometers will be needed, one for each axis to give the orientation of the craft and of course the acceleration. Because of the absolute ambiguity between gravity and acceleration, Even with an accelerometer on each axis, you cannot from one data set provide a picture of your exact orientation, so smart software will be needed to examine lengths of accelerometer data.
Three IR rangers
